Rear dump, side dump, and end dump trailers for construction, mining, and agriculture. Built with high-strength steel (Hardox 450 optional), HYVA hydraulics, and mining-grade reinforcement for Africa's toughest jobsites.
| Specification | Details |
|---|---|
| Body Capacity | 30 m³ / 40 m³ / 50 m³ / 60 m³ / 80 m³ |
| Dump Type | Rear dump (standard) / Side dump / End dump |
| Axles | 3-axle (30-50 m³) / 4-axle (60-80 m³) — FUWA or BPW |
| Hydraulic System | HYVA (imported — standard) or Domestic hydraulic cylinder |
| Body Material | High-strength steel (NM400/NM450) — Hardox 450 (optional upgrade) |
| Body Thickness | Bottom: 6-8mm / Sides: 4-6mm / Tailgate: 6mm (reinforced) |
| Suspension | Heavy-duty multi-leaf spring suspension |
| Tires | 12R22.5 (tubeless radial) — 12 pcs |
| Kingpin | 3.5" JOST (standard) / 2.0" available |
| Brake System | Dual-line air brakes with ABS — WABCO valves |
| Lining (optional) | Wear-resistant polyurethane lining for abrasive materials |
| Tailgate | Hydraulic opening tailgate (standard) / Manual (economy) |
| Dump Angle | 45-50 degrees (rear dump) |
| Paint | Sandblasting + anti-corrosion primer + 2K polyurethane |
| Warranty | 12 months structural warranty |
Huayu is our go-to manufacturer for heavy-duty dump trailers — their specialty for the African market. They use Hardox 450 wear-resistant steel, HYVA imported hydraulic cylinders, and reinforced body designs field-tested in Nigerian, Ghanaian, and Zambian mines. Huayu dump trailers are built to withstand continuous heavy loading in the harshest conditions.
Tongya offers custom dump trailer configurations with a wide range of body sizes, axle configurations, and hydraulic options. Their engineering team works with clients to design purpose-built dump trailers for specific material types and loading conditions.
Optional Hardox 450 wear-resistant steel body provides exceptional durability against abrasive materials like rock, sand, and ore — 4x longer life than standard steel.
Premium HYVA hydraulic cylinders provide reliable, powerful dumping action. Front telescopic cylinder with integrated safety valve prevents accidental lowering.
Reinforced body with box-section crossmembers, heavy-duty tailgate hinges, and impact-resistant side rails. Built for 24/7 mining operations.
Fast hydraulic cycle time — raised in 25 seconds, lowered in 15 seconds. Maximize trips per day with efficient tipping operation.
Tell us what materials you're hauling and we'll recommend the right dump trailer — rear, side, or end dump with the ideal steel grade and hydraulic system.
